Printing Roll
1.The outer diameter is 220mm(including the outer diameter size of the plate).
2.Surface grinding and hard chrome plating on 2 steel pipes.
3.Perform balance correction and ensure smooth operation. Printing Pressure Roll
1.The outer diameter is 136mm and the wall thickness is 14mm.
2.Grinding the surface of the steel pipe and plating it with hard chromium.
3.Perform balance correction to ensure smooth operation.
4.Manually adjust the gap dial of the printing press roller,with an adjustment range of 1.2-12mm.
Feeding Upper/Down Roll
1.Upper Roller:Thick walled steel pipe with an outer diameter of 71mm,equipped with two rings with an outer diameter of 104mm.
2.Lower Roller:Thick walled steel pipe with an outer diameter of φ104mm,surface polished and plated with hard chromium.
3.Manually adjust the gap dial of the paper feeding stick,with an adjustment range of 1.2-12mm.
Steel Anilox Roll
1.The outer diameter is 136mm and the wall thickness is 22mm.It is produced in Dalian.
2.Grind the surface of the steel pipe,press the mesh pattern,and coat it with hard chromium.
3.Perform balance correction to ensure smooth operation.
4.The mesh size is 220 mesh,250 mesh,etc.
5.Anilox roller with wedge type overrunning clutch,convenient and fast for ink mixing and washing.
Rubber Roll
1.The outer diameter is φ 128±0.02mm,originating from Jizhou.
2.Wrap wear-resistant rubber on the surface of the steel pipe and perform balance correction.
3.Rubber with high special grinding and good ink transfer effect.
Phase Adjustment Mechanism
1.Planetary gear structure.
2.Manually adjust the lateral position to a distance of ±5mm.
Ink Cycle
1.Pneumatic diaphragm pump,stable ink supply,easy operation and maintenance.
2.Ink filter screen,filter impurities,ink separation.
Printing Phase Fixture
1.Pneumatic automatic braking device.
2.When the machine is separated or the phase is adjusted,the brake mechanism restricts the rotation of the machine and maintains the fixed point of the original gear position.
